LoRaWAN LWHD-WM420 Long-Distance Wireless Inclinometer Accuracy 0.05°

  • 1
  • 2

Brand Name : BWSENSING

Model Number : LWHD-WM420

Place of Origin : CHINA

MOQ : 1 set

Payment Terms : T/T

Delivery Time : 5-8 working days

Packaging Details : BWSENSING BOX,Express package

Accuracy : 0.05°

Resolution : 0.001°

Measurement axis : Dual axis

Auto-sleep mode : Support

Zero temperature drift(°/℃) : ±0.001

Timed Wake-up : Support

Mean Time Between Failure : 100,000 hours

Insulation resistance : ≥100 MΩ

Contact Now

LoRaWAN LWHD-WM420 Long-distance wireless inclinometer Measurement range 0-±90° Cross-axis error 0.008°

Introduction

LoRaWAN LWHD-WM400 long-distance wireless transmission inclinometer is designed for structural health monitoring (SHM). All modules are designed with ultra-low power consumption, the sleep current is lower than 4μA, and have timed wake-up and motion detective wake-up functions. Working temperature is -40 ℃ ～ +85 ℃.

Performance index

Measuring range(°) 0~±90
Measuring axis X-Y
Accuracy(°) At room temperature 0.05
Resolution(°) Completely stationary 0.001
Zero temperature
drift(°/℃)		 -40℃〜+85℃ ±0.001
Cross-axis error(°) At room temperature 0.008
Output frequency(Hz) Up to 10 (Connect Android Phone or PC via cable), Up to 0.1 (via LoRaWAN)
Auto-sleep mode Support
Timed Wake-up Support
Movement Detected Wake-up Support
Mean Time Between Failure 100,000 hours
Electromagnetic
compatibility		 Accordance to GBT17626
Insulation resistance ≥100 MΩ
Impact-resistant 2000g,0.5ms,3Times/axis
Size(mm) L109*W88*H63mm (without antenna) L109*W88*H131mm (with radome)
Weight(g) 550(±10)(with two batteries)

LoRaWAN LWHD-WM420 Long-Distance Wireless Inclinometer Accuracy 0.05°

LoRaWAN LWHD-WM420 Long-Distance Wireless Inclinometer Accuracy 0.05°

LoRaWAN LWHD-WM420 Long-Distance Wireless Inclinometer Accuracy 0.05°

Application

Ancient building protection monitoring

Foundation pit monitoring

Dam monitoring

Tower tilt monitoring
